Air Purification Unit – 500

GENERAL SPECIFICATIONS

The Air Purification Unit – 500 is a compact self-con-rained air purification and recirculation-ton unit combining gas phase and particulate filtration. The Air Purification Unit – 500 offers maximum odor and particulate removal at high efficiency. All select-ted particulate filters and chemical media are shipped in the unit for convenience. The unit at full speed does not exceed a sound pressure level of 54 dba at a 5’ distance. The unit has a 5-foot plug, castors, and a disconnect switch or optional speed controller.

High-Efficiency Humidification with Clean Output

The humidification process utilizes the current passing through water to generate heat, causing the water to boil and produce steam, thereby achieving efficient isothermal humidification.

Compact Design

The system has a small footprint, making it well-suited for installation and operation in confined or limited spaces.

Intelligent Control

It is equipped with an intelligent control system that enables automatic humidity adjustment and supports both switch control and proportional control, meeting the needs of different environments.

Fast Response & Cost-Effectiveness

The steam output can be flexibly adjusted according to environmental requirements, with control accuracy ranging from 1% to 3%. It is cost-effective and easy to install.

Model	Unit	DJ-4	DJ-8	DJ-15	DJ-23	DJ-32	DJ-45	DJ-64	DJ-90	DJ-150
Rated Humidification Capacity	Kg/h	4	8	15	23	32	45	64	90	150
Voltage	Main circuit: three-phase AC380V, 50HZ, control loop: single-phase
Operating current	A	4.4	8.8	16.5	25.3	35.2	49.4	49.4
Absorbent	Strong	Very strong	Does not absorb water	Does not absorb water
Wet firmness	Normal	Difference	Strong	Very strong
Fire resistance	Difference	Normal	Strong	Very Strong
Areas of use	Comfort humidification	Comfort humidification	Filter and clean air, process humidification, , and air cooling	Evaporative coolers in the nuclear industry and power plants, process humidification, filtering and cleaning air
Service Life	5-7 Years	5-7 Years	15 Years	40 Years
Humidification cleanliness	Better	Not Good	Good	Good
Descaling and Cleanning	OK	Not Easy	Easy	Easy

Working Principle: Clean tap water, passed through an electromagnetic valve, is delivered to the top water distributor of the wet membrane via the water supply pipeline. Under the influence of gravity, the water flows down along the surface of the wet membrane, wetting the membrane’s surface. The water that flows into the water collection tray is then drained through a siphon pipe to the sewage system, meaning the water is not recirculated.

TECH-CHEK™ SERVICE

Our Circul-Aire MULTI-MIX® media is engineered to be non-toxic and nonhazardous, ensuring safe use across various applications. It does not support bacterial or fungal growth, making it ideal for maintaining clean and healthy environments. UL Class 1 listed, this media is recognized as nonflammable, offering additional safety benefits. For optimal performance, Circul-Aire offers TECH-CHEK™ Service, providing laboratory testing and analysis to determine the remaining service life of the media. Moreover, our MULTI-MIX® media is fully compatible with other Circul-Aire products, ensuring seamless integration within your existing systems.
